High Output Polypropylene PP Strap Making Machine Excellent Plasticization 5-19mm

Name: High Output Polypropylene PP Strap Making Machine Excellent Plasticization 519mm
Brand: JIATUO CHINA
Price: 1 USD

Quality High Output Polypropylene PP Strap Making Machine Excellent Plasticization 5-19mm for sale

Brand Name : JIATUO CHINA

Model Number : JTPP

Certification : ISO/ CE

Place of Origin : CHINA

MOQ : 1 SET

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 50-60DAYS To be negotiated

Packaging Details : Plastic film

Plastic Processed : PP

production capacity : 120-600kgs/H

Warranty : 1 years

Number of extruded strap : 2/3/4/6/8

Application Scope : some light cargoes (>240kgs)

screen changer : Automatic/Manual

Thickness range : 0.4-1.2mm

Width range : 5-19mm

Applicable raw materials : Recycled material and Polypropylene

Melting point : 260 temperature

Keywords : Strap Making Machine

Key Selling Points : High Productivity

Automatic Grade : Fully automatic/ semi automatic

Inveter : IVNT

Motor : Siemens

Worn parts : Provide some for free

Voltage : According to customer's requests

Winder type : Fully automatic/ Semi automatic

Contact Now

High Output Polypropylene PP Strap Making Machine Excellent Plasticization 5-19mm

Product Description of PP strap making machine

This plastic machine PP strap band product for packaging. This line is comparatively low cost. The line speed is >250mm/min. The width and thickness of the strap band is adjustable.
PP Bale Strap Machine is a renewed and improved design, and is special for producing the polypropylene packing strip.
The whole machine includes the extruder, mould, cooling tank, haul-off device, embossing device, winder and electrics controlling part.

Compositions of PP belt production line

1	Vacuum feeder
2	Hopper dryer
3	Feeding machine
4	¢90-135mm Extruding Machine
5	Automatic Screen filter changer
6	Mould(1 mould for 2/3/4/6/8 output)
7	Water cooling tank system
8	The first haul-off device
9	Stretching oven
10	The second haul-off device
11	PLC electrical control system
12	Embossing machine
13	Forming oven
14	Cooling system
15	The third haul-off device
16	Double disk winder

High Output Polypropylene PP Strap Making Machine Excellent Plasticization 5-19mm

Application of PP strapping
PP strap have been widely used in the package of steel, paper, lumber, tobacco, bricks, building materials, chemical fiber,cotton, metal products, and many other sectors.

Advantage of PP belt production line

PP strap band making machine by single screw extruder or double screw
• Comply with strict safety standards, production lines have longer life.
• From raw material processing, extrusion, drawing, embossing, cooling and winding; every step to improve and ensure the quality of packing
• The entire line can be controlled via a touch screen.
• Production speeds can be up to 250m/min, low waste.
• Choice of two,four, six and eight straps production line.
